“STRIZH–M3” optronic station

The optronic station is designed for day-and-night detection of airborne and ground-based targets, determination of their coordinates. It can be used to replace the standard TV optical viewfinder at missile guidance stations of air defense missile systems. It can be used to replace standard TV optical viewfinder of short range ADMS.

Tactical and technical characteristics

Channel
Television
Thermal
Type of receiver, μm
CMOS NIR-enhanced
uncooled microbolometer 17
Spectral sensitivity, μm
0.4-1.1
8-14
Receiver resolution
1600x1200
640х480
Objective, narrow field
F1.8/100
F1.0/150
Objective, wide field
F1.4/35
F1.2/50
Narrow field of view
4°x3°
Wide field of view
12°x9°
Image transfer
Ethernet
Frame rate, Hz
30
Control
Ethernet
Battery/Power, V
19-32
Power consumption, W
120
Operation temperature range, °С
-40...+50
