Technical specifications
| Channel
|
Television
|
Thermal
|
| Type of receiver, μm
|
CMOS NIR-enhanced
|
uncooled microbolometer 17
|
| Spectral sensitivity, μm
|
0.4-1.1
|
8-14
|
| Receiver resolution
|
2590x2048
|
640х480
|
| Lens, narrow field
|
F1.5/150
|
F1.0/150
|
| Lens, wide field
|
F0.95/50
|
F1.2/50
|
| Narrow field of view
|
4°x3°
|
|
| Wide field of view
|
12°x9°
|
|
| Rangefinder operation distance, km
|
20
|
|
| Image transfer
|
Ethernet
|
|
| Frame rate, Hz
|
30
|
|
| Control
|
Ethernet
|
|
| Battery/Power, V
|
19-32
|
|
| Power consumption, W
|
120
|
|
| Operation temperature range, °С
|
-40...+50
|
|
